Legend REVO-A M8 Softail Monoshock

(1 customer review)

$999.95

  • Revo-A coil designed specifically for M-8 Softail models
  • Available in 12.5″, 13″, and 13.5″, standard or heavy-duty applications
  • Adjustable preload for rider set up, also allows for minimal pre-load adjustment when changing between rider’s weights and loads
  • Legend’s touring specific spring rates provide superior ride comfort, improved performance, and increased resistance to bottoming for all day comfort
  • Features adjustable rebound damping that is specifically designed to make fast, precise, and repeatable changes to ride comfort and performance with a simple turn of a knob
  • Provides optimum rebound performance that can be fine-tuned for any given rider weight, personal ride preference, or personal riding style
  • Low friction sleeve bearings both top and bottom for ease of installation, this also allows the shock to float in its mount and avoid shock bind
  • Hard anodized, 46 mm billet aluminum mono tube design utilizes a lightweight high flow piston design for improved fluid flow resulting in unmatched handling and bike control
  • Hard chromed shaft is 14% larger for increased strength
  • Internal floating nitrogen piston ensures consistent damping performance
  • Deflective disc valving self-adjusts to frequency and ensures controlled performance
  • Legend’s durable and low friction sealing system and sliding bearings provide improved performance and feel
  • Available in Black Type III hard coat anodize
  • Easy installation that utilizes the OEM mounting hardware
  • Included preload wrench makes adjusting easy
  • Sold as Mono Shock (1 shock only)
  • Designed for optimum performance with the Legend Axeo front suspension
  • Made by hand in Sturgis, SD, USA

12.5″ = Factory Replacement Length

13″ = Performance and resistance to bottoming out

13.5″ = Increases shock travel

Description

Legend REVO-A Adjustable M8 Softail Monoshock

  • Revo-A coil designed specifically for M8 Softail models
  • Available in 12.5″, 13″, and 13.5″, standard or heavy-duty applications
  • Adjustable preload for rider set up, also allows for minimal pre-load adjustment when changing between rider’s weights and loads
  • Legend’s touring specific spring rates provide superior ride comfort, improved performance, and increased resistance to bottoming for all day comfort
  • Features adjustable rebound damping that is specifically designed to make fast, precise, and repeatable changes to ride comfort and performance with a simple turn of a knob
  • Provides optimum rebound performance that can be fine-tuned for any given rider weight, personal ride preference, or personal riding style
  • Low friction sleeve bearings both top and bottom for ease of installation, this also allows the shock to float in its mount and avoid shock bind
  • Hard anodized, 46 mm billet aluminum mono tube design utilizes a lightweight high flow piston design for improved fluid flow resulting in unmatched handling and bike control
  • Hard chromed shaft is 14% larger for increased strength
  • Internal floating nitrogen piston ensures consistent damping performance
  • Deflective disc valving self-adjusts to frequency and ensures controlled performance
  • Legend’s durable and low friction sealing system and sliding bearings provide improved performance and feel
  • Available in Black Type III hard coat anodize
  • Easy installation that utilizes the OEM mounting hardware
  • Included preload wrench makes adjusting easy
  • Sold as Mono Shock (1 shock only)
  • Designed for optimum performance with the Legend Axeo front suspension
  • Made by hand in Sturgis, SD, USA

More Monoshock options HERE.

Fitment Guide:

2020-2023 Harley-Davidson Softail Low Rider S FXLRS
2020-2023 Harley-Davidson Softail Standard FXST
2019-2020 Harley-Davidson FXDR 114
2018-2023 Harley-Davidson Softail Fat Boy 114 FLFBS
2018-2023 Harley-Davidson Softail Fat Bob 114 FXFBS
2018-2023 Harley-Davidson Softail Heritage Classic 114 FLHCS
2018-2022 Harley-Davidson Softail Street Bob FXBB
2018-2021 Harley-Davidson Softail Heritage Classic FLHC
2018-2021 Harley-Davidson Softail Slim FLSL
2018-2021 Harley-Davidson Softail Sport Glide FLSB
2018-2020 Harley-Davidson Softail Breakout 114 FXBRS
2018-2020 Harley-Davidson Softail Deluxe FLDE
2018-2020 Harley-Davidson Softail Low Rider FXLR
2018-2019 Harley-Davidson Softail Breakout FXBR
2018-2019 Harley-Davidson Softail Fat Boy FLFB
2018-2019 Harley-Davidson Softail Fat Bob FXFB
2016-2017 Harley-Davidson Softail Slim S FLSS
2016-2017 Harley-Davidson Fat Boy S FLSTFBS
2016-2017 Harley-Davidson CVO Pro Street Breakout FXSE
2015-2017 Harley-Davidson Softail Slim FLS
2015-2017 Harley-Davidson Fat Boy Lo FLSTFB
2015-2017 Harley-Davidson Breakout FXSB
2015-2017 Harley-Davidson Softail Fat Boy EFI FLSTFI
2015-2017 Harley-Davidson Softail Deluxe EFI FLSTNI
2015-2017 Harley-Davidson Softail Heritage Classic EFI FLSTCI
2015 Harley-Davidson CVO Softail Deluxe FLSTNSE

Info Video

Additional information

Weight 10 lbs
Dimensions 5.97 × 16.1 × 15.38 in
Size

12.5", 13", 13.5"

Choose One

Standard, Heavy Duty
